PTZ Intelligent Tracking Camera

This series camera has perfect functions, superior performance and rich video output interfaces; Featuring advanced ISP processing algorithms, offering vivid and high-resolution video with a strong sense of depth and fantastic color rendition. It supports H.264/H.265 encoding which makes motion video more fluent and clear under low bandwidth conditions.

4K to 1080P optional

Multiple Optical Zoom Lens: 12X/20X optical zoom lens.

Leading Auto Focus Technology: Fast, accurate, and stable auto-focusing technology.

Low Noise and High SNR: Super high SNR image is achieved with low noise CMOS. Advanced 2D/3D noise reduction technology further reduces the noise while ensuring high image clarity.

Multiple Video Output Interfaces: HDMI, SDI, USB3.0, LAN(POE); Simultaneously output audio and video signal via HDMI, SDI, USB3.0, and LAN; SDI output could up to 100M with 1080P@60fps.

USB3.0 supports dual code streams: Supports both main and sub-code streams output simultaneously; supports YUY2, MJPEG, H.264, NV12, and H.265 video encoding format.

Multiple Audio Compression Standards: Support AAC, MP3, and G.711A audio compression, 8000, 16000, 32000, 44100, 48000 sampling frequency.

Built-in Gravity Sensor: Support automatic PTZ auto-flip function and easy to install.

Multiple Network Protocol: Support ONVIF, GB/T28181, RTSP, RTMP protocols; Support RTMP push mode, easy to be

connected to streaming server (Wowza, FMS); Support RTP multicast mode; Support network full command VISCA control protocol.

Control Interface: RS422 (compatible with RS485), RS232 in & out ;RS232 (cascade connection).

Multiple Control Protocol: Support VISCA, PELCO-D, and PELCO-P protocols; Support automatic identification protocols.

Quiet Pan / Tilt Movement: With high accuracy step driving motor, the camera can pan/tilt extremely quietly and smoothly.

Multiple Presets: Up to 255 presets (10 presets via remote control).

IR / Wireless Remote Control: Users can choose IR remote control or wireless remote control according to different conditions. 2.4G wireless remote control is not affected by the angle, distance, or infrared interference. Far-end control is also available.

Multiple Applications: Online education, Lecture Capture, Webcasting, Video conferencing, Telemedicine, Unified Communication, Emergency command and control systems, etc.
